Product Information
The Sierra Wireless AirLink RX400 in this model is a wired 5G RedCap and LTE Cat 4 router with a Gigabit Ethernet port, an RS-232 serial port and USB-C. It uses FIPS 140-2 Level 1 encryption, is FirstNet ready and runs AirLink OS, and quick specs list 1 year of AirLink Complete. No Wi-Fi is listed for this SKU.
Key Features
- 5G RedCap and LTE Cat 4, 2 x Nano SIM
- 1 x GbE LAN, RS-232 RJ-45, USB-C
- FIPS 140-2 Level 1, FirstNet ready
- AirLink OS, ALMS management
- ARM Cortex-A55, 600 MB RAM
- 1 year AirLink Complete per quick specs
Product Information
Product Type #2: Wireless cellular modem
Brand: Sierra Wireless
Manufacturer: Sierra Wireless
Product Line: Sierra Wireless AirLink
Model: RX400
Product Type: Router
Product Type: Wireless cellular modem
Packaged Quantity: 1
Country: Global
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: Ethernet, Fast Ethernet, Gigabit Ethernet
Routing Protocol: Policy-based routing (PBR), Static IPv4 routing, Static IPv6 routing
Bridge & Router: 5G downlink bandwidth: 226 Mbps, 5G uplink bandwidth: 120 Mbps
Authentication Method: RADIUS
Encryption: 128-bit AES, 192-bit AES, 256-bit AES, 256-bit SHA, 384-bit SHA, 512-bit SHA, FIPS 140-2 Level 1, IKEv1, IKEv2
Cellular Data Connectivity Technology: 5G RedCap, LTE Cat4
Operating System Edition: AirLink OS
Key Features: Firewall, USB port, VPN support
Features: 2x2 MIMO technology, 802.1x authentication, Aluminum housing, Authentication, Authorization and Accounting (AAA), DHCP server, Dual core CPU, Firmware upgradable, FirstNet ready, IP passthrough, LAN segmentation, NAT support, Port forwarding, Quality of Service (QoS), Rugged, Static routing
Software Type: AirLink Management Service (ALMS)
Connectivity
Interface Provided: Antenna: 1 x SMA - 5G, Antenna: 1 x SMA - GNSS antenna, LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45, Serial: 1 x RS-232 - RJ-45, USB: 1 x 24 pin USB-C
Expansion Slots: 2 (total) / 2 (free) x Nano-SIM
Power
Device Type: Internal power supply
Memory and Processor
Processor Brand: ARM
Processor Number: Cortex-A55
Processors Installed: 1
RAM Installed: 600 megabyte
Flash Memory Installed: 500 megabyte
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: Up to 95% RH
MTBF: 96.94 Year
Physical Characteristics
Form Factor (Hubs & Switches): Desktop
Built-in Devices: GNSS receiver
Dimensions and Weight
Height: 1.3 inch
Width: 4.6 inch
Depth: 3.3 inch
Weight: 12.36 ounce
Included Items
Included Accessories: Power cable
Warranty
Service Activation: No
