Product Information
The Sierra Wireless AirLink XR60 is a rugged 5G in-vehicle router rated from -40 to 75 C. It has a 5GbE and a GbE port, USB-C, GPIO, dual Nano-SIM and GNSS, with up to 2800 Mbps downlink and 800 Mbps firewall throughput. Quick specs list 5 years of AirLink Complete. The specs list no Wi-Fi radio.
Key Features
- 5G, LTE and HSPA+, dual Nano-SIM
- 1 x 5GbE, 1 x GbE, USB-C, GPIO
- Up to 2800 Mbps down, 900 Mbps up
- 800 Mbps firewall, 175 Mbps IPSec VPN
- FIPS 140-2 Level 1, FirstNet ready
- Aluminum housing, 4 GB RAM, power cable included
Product Information
Product Type #2: Wireless cellular modem
Brand: Sierra Wireless
Manufacturer: Sierra Wireless
Product Line: Sierra Wireless AirLink
Model: XR60
Product Type: Router
Product Type: Wireless cellular modem
Packaged Quantity: 1
Country: Global
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: IPv4, IPv6
Bridge & Router: Downlink bandwidth: 2800 Mbps, Firewall throughput (TCP): 800 Mbps, Uplink bandwidth: 900 Mbps, VPN throughput (IPSec): 175 Mbps
Encryption: 128-bit AES, 192-bit AES, 256-bit AES, DH, FIPS 140-2 Level 1, IKEv1, IKEv2, SHA-256, SHA-384, SHA-512
Modem Transmission Data Rate: 2800 MBps
Cellular Data Connectivity Technology: 5G, HSPA+, LTE
Operating System Edition: AirLink OS
Key Features: Firewall, USB port, VPN support
Features: 4x4 MIMO technology, Aluminum housing, Dead Peer Detection (DPD), DHCP server, FirstNet ready, IP passthrough, LAN segmentation, NAT support, Policy based routing, Port forwarding, QoS, Reconfigurable MTU size, Static routing
Software Type: AirLink Management Service (ALMS)
Connectivity
Interface Provided: 1 x GPIO, Antenna: 1 x SMA - GNSS antenna, Antenna: 4 x SMA - 5G, LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45, LAN: 1 x 5GBase-T - RJ-45, USB 3.2 Gen 1: 1 x 24 pin USB-C
Expansion Slots: 2 Nano-SIM
Memory and Processor
RAM Installed: 4 GB
Flash Memory Installed: 512 megabyte
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 167 degree Fahrenheit
Operating Humidity: 95% RH
MTBF: 30.13 Year
Physical Characteristics
Form Factor (Hubs & Switches): In-vehicle
Built-in Devices: GNSS receiver
Dimensions and Weight
Height: 3.9 inch
Width: 4.6 inch
Depth: 1.5 inch
Included Items
Included Accessories: Power cable
Warranty
Service Activation: No
