Product Information
The Sierra Wireless AirLink XR80 Base is a 5G router for fixed and mobile use, with a 5GbE port, an aluminum housing and a quad core CPU. It offers up to 4.5 Gbps downlink, 1150 Mbps firewall throughput and FIPS 140-2 Level 1 encryption. Quick specs list 1 year of AirLink Complete. No Wi-Fi is listed for this Base edition.
Key Features
- 5G, LTE CAT20 and HSPA+, up to 4.5 Gbps down
- 5 Gigabit Ethernet, no Wi-Fi listed
- 1150 Mbps firewall, 10 VPN tunnels
- FIPS 140-2 Level 1, 2 x Mini SIM, LPWA
- AirLink OS, ALMS management
- 1 year AirLink Complete per quick specs
Product Information
Product Type #2: Wireless cellular modem
Brand: Sierra Wireless
Manufacturer: Sierra Wireless
Product Line: Sierra Wireless AirLink
Model: XR80
Product Type: Router
Product Type: Wireless cellular modem
Packaged Quantity: 1
Country: North America
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Network Standard: IPSec, IPv4, IPv6, TCP/IP
Routing Protocol: Policy-based routing (PBR), Static IPv4 routing, Static IPv6 routing
Bridge & Router: Downlink bandwidth: 4.5 Gbps, Firewall throughput: 1150 Mbps, Uplink bandwidth: 900 Mbps
Authentication Method: RADIUS
Encryption: 128-bit AES, 192-bit AES, 256-bit AES, 256-bit SHA, 384-bit SHA, 512-bit SHA, FIPS 140-2 Level 1, IKEv1, IKEv2
Modem Transmission Data Rate: 4.5 GBps
Capacity: Concurrent VPN tunnels: 10
Cellular Data Connectivity Technology: 5G, HSPA+, LTE CAT20
IoT Communications Technology: 5G, LPWA
Internet of Things (IoT) Compatible: Yes
Operating System Edition: AirLink OS
Key Features: Firewall, USB port, VPN support
Features: 4x4 MIMO technology, Aluminum housing, Dead Peer Detection (DPD), DHCP server, DMZ support, Firmware upgradable, IP passthrough, LAN segmentation, NAT support, Port forwarding, Quad-core CPU, Quality of Service (QoS), Reconfigurable MTU size, Static routing, Tunneling
Software Type: AirLink Management Service (ALMS)
Edition: Base
Connectivity
Expansion Slots: 2 Mini-SIM
Power
Device Type: Internal power supply
Memory and Processor
Processor Brand: ARM
RAM Installed: 200 megabyte
Flash Memory Installed: 750 megabyte
Technical Information
Min Operating Temperature: -22 degree Fahrenheit
Max Operating Temperature: 140 degree Fahrenheit
MTBF: 23.8 Year
Physical Characteristics
Form Factor (Hubs & Switches): Desktop
Dimensions and Weight
Height: 2.1 inch
Width: 8.7 inch
Depth: 6.7 inch
Weight: 3.97 lbs
Included Items
Included Accessories: LPWA antenna, Power cable
Warranty
Service Activation: No
