Product Information
The SIIG CE-H26B11-S1 is a 1 in, 2 out HDMI splitter, not an antenna. It sends one HDMI source to two displays at up to 3840 x 2160 at 60 Hz with HDR (4K60 10-bit 4:2:0), Dolby Vision, Dolby TrueHD, Dolby Digital and DTS-HD support. EDID management and a downscaler help different displays work together, the firmware can be updated, and the black metal housing sits on a desk. It is powered through micro-USB from an external adapter, and a micro-USB to USB cable is included.
Key Features
- HDMI splitter, not an antenna
- 1 input to 2 HDMI outputs
- 4K at 60 Hz with HDR
- EDID management, downscaler
- Dolby and DTS-HD audio
- Black metal desktop housing
Product Information
Brand: SIIG
Manufacturer: Siig
Product Line: SIIG
Model: 2 Port HDMI 4K HDR Splitter with EDID and Downscaler
Product Type: Video/audio splitter
Subcategory: Peripheral sharing and hubs
Packaged Quantity: 1
Color: Black
Color Category: Black
Network and Communication
Switching Type: HDMI
Features: 4K resolution support, Dolby Digital support, Dolby TrueHD support, Dolby Vision HDR support, Down-scaling, DTS-HD support, EDID Management, Firmware upgradable, HDR 4K60 10-bit 4:2:0 compatible, Metal housing
KVP Max Resolution: 3840 x 2160
Connectivity
Ports: 2
Port Quantity: 2
Port Type: HDMI
Interface Provided: 1 x HDMI input, 1 x micro-USB management / power, 2 x HDMI output
Power
Device Type: External power adapter
Frequency: 50/60 hertz
Electric Current Required: 1 A
Technical Information
KVM V-Sync Rate At Max Resolution: 60 Hz
Min Operating Temperature: 23 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 90% (non-condensing)
Min Storage Temperature: -4 degree Fahrenheit
Max Storage Temperature: 140 degree Fahrenheit
Physical Characteristics
Form Factor (Hubs & Switches): Desktop
Dimensions and Weight
Height: 0.7 inch
Width: 3.5 inch
Depth: 2.4 inch
Weight: 4.16 ounce
Included Items
Cables: 1 x micro-USB to USB cable
Certifications and Listing
Compliant Standards #2: FCC, RoHS
Compliant Standards: HDCP 2.2
Compliant Standards: FCC, RoHS
Warranty
Service Activation: No
