Product Information
The Sony BRC-AM7 is a white 4K PTZ camera with an Exmor RS CMOS sensor running up to 60 fps, 20x optical zoom, built in optical ND filters, phase detection autofocus and face detection. It offers 12G-SDI, 3G-SDI, HDMI and SFP+ outputs, XLR audio inputs, NDI HX, SRT and RTMP streaming and CFexpress/SD recording, on 12 V DC or PoE. It is a broadcast/production camera, not a security camera.
Key Features
- 4K at 60 fps
- 20x optical zoom
- Optical ND filters
- 12G-SDI, SFP+, HDMI
- NDI HX, SRT, RTMP
- 12 V DC or PoE, white
Product Information
Brand: Sony
Manufacturer: Sony
Product Line: Sony
Model: BRC-AM7
Packaged Quantity: 1
Color: White
Color Category: White
Network and Communication
Features: 1/4"-20 UNC mounting, 3/8"-20 UNC mounting, 709tone compatibility, Built-in optical ND filters, Contrast detection AF, Face Detection, Human pose estimation, ITU709 compatibility, Phase Detection Auto Focus (PDAF), PoE++ support, PTZ Auto Framing, S-Cinetone, S-Log3 gamma setting, Subject tracking technology, Tally light
Connectivity
Protocols: NDI HX, RTMP, RTSP, SRT, VISCA
Ports: 12G-SDI output - BNC, 2 x remote control - RJ-45, 3G-SDI output - BNC, Audio line in - 3 pin XLR x 2, Audio line-in/microphone - 3.5 mm jack, Digital input - SFP+, Genlock - SFP+, HDMI output - HDMI Type A, LAN - RJ-45
Power
Low Voltage Power: DC 12 V / PoE Plus Class 4
Power Device Form Factor: External
Power Device Type: Power adapter
Memory and Processor
Memory Cards Supported: CFexpress, SD Memory Card
Technical Information
Angular Field of View (H, Max, Degree): 75
Video Signals: 12G-SDI, 3G-SDI, HDMI
Optical Zoom: 20
Digital Zoom: 40
Max Panning Speed (degree/sec): 180
Max Tilting Speed (degree/sec): 180
Tilt: -30 to +210
Panning Range (degree): -175 to +175
Min Focus Distance: 0.4 inch
Video Modes: 1080p, 4K/60p, 720p
Image Sensor Type: Exmor RS CMOS
Lens Aperture: F/2.8-4.5
Digital Video Capture Resolution: 1920 x 1080, 3840 x 2160, 720 x 480, 720 x 576
Max Frame Rate: 60 frames per second
Shutter Speed (Max): 1/8000 second (time unit)
Video Formats: AVC-LongG, HEVC, XAVC HS, XAVC S, XAVC S-I
Video Input: Color
Audio Support: Yes
Audio Formats: LPCM
Touchscreen: No
Supported Host Device Platform: Android, iPadOS, MacOS, Windows
Max Video Resolution: 3840 x 2160
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Physical Characteristics
Theft Protection: Security lock slot (cable lock sold separately)
Security Slot Type: Kensington security slot
Camera Mechanical Design: Pan / tilt / zoom
Dimensions and Weight
Height: 7.6 inch
Width: 6.6 inch
Depth: 8.9 inch
Weight: 8.16 lbs
