Product Information
StarTech.com's 117B-USBC-MULTIPORT is a portable USB-C dock that drives up to three displays via MST, up to one 4K 60 Hz plus two 4K 30 Hz, from two HDMI 2.0b and two DisplayPort 1.2 outputs. It also provides three 10 Gbps USB-A ports, Gigabit Ethernet and a 100W USB-C PD pass-through port.
Key Features:
- 2x HDMI 2.0b + 2x DisplayPort 1.2 (up to 3 displays)
- 1x 4K 60 Hz + 2x 4K 30 Hz via MST
- Three USB-A ports at 10 Gbps
- Gigabit Ethernet (RJ-45)
- USB-C PD 3.0 pass-through up to 100W
- Works with USB-C, USB4, Thunderbolt 3/4; Windows and ChromeOS
Specifications:
- Brand: StarTech.com
- Manufacturer Part Number: 117B-USBC-MULTIPORT
- Max Data Rate: 1.25 GBps
- Data Link Protocols: Gigabit Ethernet
- Host Connection: USB 3.2 (Gen 2) Type C
- HDMI Ports: 2
- HDMI Version: 2.0b
- Network (RJ-45): Yes
- Network (RJ-45) Ports: 1
- RJ-45 Ports: 1
- Total USB Ports: 5
- USB-A Ports: 3
- USB-C Port Detail: 1 USB Type-C (24 pin) USB Power Delivery Only, 1 USB 3.2 Type-C (24 pin, Gen 2, 10Gbps)
- USB-C Ports: 2
- Maximum Resolution: 3840 x 2160
- Power Source Type: Power Adapter
- Compatible Device Types: Desktop PC, Monitor, Notebook
- Displays Supported: 3
- Product Category: Docking Station
- Listed Dimensions: Height 0.71 in, Width 2.20 in
- Weight: 3.99 oz
