Product Information
The Taoglas TS.07 is a compact, high efficiency hinged monopole antenna for GPS, GLONASS, Galileo and BeiDou, with a rotatable SMA male connector. It suits vehicle trackers and telematics devices and measures about 2.8 in.
Key Features
- GNSS: GPS, GLONASS, Galileo, BeiDou
- Hinged, rotatable
- SMA male
- Omni monopole
- About 2.8 in tall
- Orange brass body
Product Information
Brand: Taoglas
Manufacturer: Taoglas USA Inc
Product Line: Taoglas
Model: TS.07
Packaged Quantity: 1
Color Category: Orange
Network and Communication
Antenna Compatibility: BeiDou, GALILEO, GLONASS, GPS
Frequency Range: 1561 MHz, 1575.42 MHz, 1602 MHz
Signaling Type: Navigation
Antenna Type: Antenna
Directivity: Omni-directional
Connectivity
Connectors: 1 x antenna - SMA (male)
Technical Information
Impedance: 50 ohm
Antenna Form Type: Monopole
Antenna Features: Linear polarization
Max Power: 10 watt
Physical Characteristics
Materials: Brass
Dimensions and Weight
Height: 2.8 inch
Width: 0.4 inch
Depth: 0.4 inch
Weight: 0.21 ounce
Warranty
Service Activation: No
Not sure this antenna fits your hardware? Send us your access point or radio model and the DatorPro team will confirm the connector and compatibility before you order.
