Product Information
The B126-002 splits one HDMI signal into two and sends each over a single Cat5e/6 cable to a remote display. With an active remote unit (B126-1A0 or B126-1A0-WP), 1080i (60Hz) reaches up to 200 ft and 1080p (60Hz) up to 150 ft. With a passive remote unit (B126-1P0 or B126-1P0-WP), 1080i reaches 100 ft and 1080p 50 ft. 24 AWG solid-wire Cat5e/6 cable (Tripp Lite N202-Series) is required for maximum distance. It supports stereo and 7.1-channel audio and HDCP content, and included hardware allows rack, wall or pole mounting. It is TAA compliant. Backed by a 1 year limited warranty.
Key Features
- 2-port HDMI over Cat5/6 splitter / transmitter
- 1080p up to 150 ft with active receivers
- Stereo and 7.1 audio, HDCP
- Rack, wall or pole mountable
- TAA compliant
- 1 year limited warranty
Product Information
Brand: Tripp Lite
Manufacturer: Tripplite Cables
Product Line: Eaton Tripp Lite Series
Model: B126-002
Product Type: Video/audio extender
Form Factor: External
Technical Information
Features: HDCP compliant, Wall mountable
Dimensions and Weight
Width: 2.5 inch
Height: 1 inch
Depth: 3.6 inch
Color: Black
Included Item
Packaged Quantity: 1
Additional Information
Connectivity Technology: Wired
Max Transfer Distance: 200 ft
Ports: 2
Transmission Medium: CAT 5/6
Interface Provided: 1 x HDMI (input) female, 2 x network - RJ-45 female
KVP Max Resolution: 1080p
Frequency: 50/60 hertz
Device Type: External power adapter
Mounting Kit: Included
Rack Mounting Kit: Optional
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Certifications and Listing
Compliant Standards: Plug and Play, RoHS
Warranty
Limited Warranty: 1 Year
