Product Information
The Ubiquiti IsoStation 5AC is an airMAX ac radio with a 14 dBi isolated beam antenna and a die cast aluminum base, used for point to point or point to multipoint links at up to 450+ Mbps. It has a Gigabit PoE port, 64 MB RAM, about 8.5 W draw, a -40 to 158 °F range and a pole mount. This is a wireless bridge radio, not a Wi-Fi access point.
Key Features
- 5 GHz airMAX ac
- 14 dBi isolated antenna
- Up to 450+ Mbps
- Gigabit RJ-45, PoE
- -40 to 158 °F
- Pole mount included
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti IsoStation ac
Model: IS-5AC
Product Type: Wireless bridge
Packaged Quantity: 1
Country: United States
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: AirMax ac
Wireless LAN: AirMax ac
Network Device: Throughput: 450 Mbps
Antenna Gain Level: 14 DBi
Operating System Edition: AirOS 8
Features: 24KV ESD Protector, Pole mountable
Connectivity
Interface Provided: 1 x 1000Base-T (PoE) - RJ-45
Power Over Ethernet (PoE): PoE
Power
Power Consumption Operational: 8.5 watt
Memory and Processor
Processor Type: MIPS 74K
Processors Installed: 1
RAM Installed: 64 megabyte
Memory Technology: DDR2 SDRAM
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 158 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor: External
Status Indicators: Power
Dimensions and Weight
Height: 5.2 inch
Width: 2.6 inch
Depth: 5.2 inch
Weight: 14.4 ounce
Included Items
Included Accessories: Pole mount
Warranty
Service Activation: No
