Product Information
The Ubiquiti LTU-LR-US is a 5 GHz point to multipoint client radio with an integrated 26 dBi antenna, a bridge radio rather than a standalone antenna. LTU technology goes beyond standard 802.11 with 1024 QAM and channel widths of 10 to 50 MHz, and the link is rated up to 19 miles in open space. It runs airOS LTU, has one gigabit PoE port, draws about 8.5 W and has a UV stabilized outdoor housing with 24 kV ESD protection. A PoE injector and pole mount are included.
Key Features
- Client radio, not an antenna
- 5 GHz LTU point to multipoint
- Integrated 26 dBi antenna
- Up to 19 miles
- Gigabit PoE port, 8.5 W
- PoE injector and pole mount
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti
Model: LTU LR
Product Type: Wireless bridge
Device Type: Power injector
Packaged Quantity: 1
Color Category: White
Country: United States
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: LTU
Line Coding Format: 1024 QAM
Wireless LAN: LTU
Network Band: 5 GHz
Antenna Form Factor: Internal
Antenna Gain Level: 26 DBi
Max Range Open Space: 19 miles
Operating System Edition: AirOS LTU
Features: 24KV ESD Protector (air-gap discharge), 24KV ESD Protector (contact discharge), Point-to-Multipoint (PtMP) link mode, UV stabilized enclosure
Connectivity
Interface Provided: 1 x 1000Base-T (PoE) - RJ-45
Power Over Ethernet (PoE): PoE
Power
Power Consumption Operational: 8.5 watt
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 140 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Ruggedized Design: Outdoor
Physical Characteristics
Form Factor: External
Dimensions and Weight
Height: 15.2 inch
Width: 20.2 inch
Depth: 10.2 inch
Weight: 3 lbs
Included Items
Included Accessories: Pole mount
Certifications and Listing
Compliant Standards: FCC, FCC Part 15 A, IC, ICES-003 Class A, NMB-3 Class A
