Product Information
The Ubiquiti LTU-XR is a 5 GHz LTU point to multipoint client radio with an integrated 29 dBi antenna using InnerFeed, rather than a standalone antenna. It is rated for up to 900 Mbps and up to 19 miles, with an LTU core processor, a dedicated spectrum analysis radio, auto distance adjustment, GPS and Bluetooth setup. It supports router mode, SSH, SNMP, DDNS and ping watchdog, AES and WPA2-PSK encryption, and has one gigabit passive PoE port in a UV stabilized pole mount enclosure. A PoE injector is included.
Key Features
- Client radio, not an antenna
- 5 GHz LTU, 29 dBi
- Up to 900 Mbps, 19 miles
- Spectrum analysis radio
- GPS and Bluetooth setup
- PoE injector included
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti
Model: LTU XR
Product Type: Wireless bridge
Device Type: Power injector
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: LTU
Network Standard: DDNS
Remote Management: SNMP, SSH
Encryption: AES, WPA2-PSK
Data Transfer Rate: 900 MBps
Wireless LAN: LTU
Antenna Form Factor: Internal
Antenna Gain Level: 29 DBi
Max Range Open Space: 19 miles
Frequency Band: 5 GHZ
Operating System Edition: AirOS
Features: Auto distance adjustment, Bluetooth management, Dedicated spectral analysis radio, Ping watchdog, Point-to-Multipoint (PtMP) link mode, Router mode, UV stabilized enclosure, Web server
Connectivity
Interface Provided: 1 x 1000Base-T (PoE) - RJ-45
Power Over Ethernet (PoE): Passive PoE
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 131 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor: Pole mountable
Status Indicators: Ethernet link/activity, Power
Built-in Devices: GPS
Dimensions and Weight
Height: 20.7 inch
Width: 29.4 inch
Depth: 13.7 inch
Weight: 7.05 lbs
Certifications and Listing
Compliant Standards: FCC, IC, IPX6
