Product Information
The Ubiquiti NanoBeam M5 16 is a 5 GHz airMAX bridge radio with a 16 dBi high gain directional antenna and three axis alignment. It has a 10/100 PoE port, 64 MB RAM, about 6 W draw, a -40 to 167 °F range and a pole mount. This is a point to point bridge radio, not a Wi-Fi access point.
Key Features
- 5 GHz airMAX bridge
- 16 dBi directional antenna
- 10/100 RJ-45, PoE
- About 6 W
- -40 to 167 °F
- Pole or wall mount
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti NanoBeam M
Model: NBE-M5-16
Product Type: Wireless bridge
Device Type: Power injector
Packaged Quantity: 1
Country: United States
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: AirMax
Wireless LAN: AirMax
Network Band: 5 GHz
Antennas: 1
Antenna Gain Level: 16 DBi
Features: airControl, airView, Pole mountable, Quality of Service (QoS), Reset button, Wall mountable
Connectivity
Interface Provided: 1 x 100Base-TX (PoE) - RJ-45
Power Over Ethernet (PoE): PoE
Power
Power Consumption Operational: 6 watt
Memory and Processor
Processor Brand: Atheros
Processor Type: MIPS 74KC
Clock Speed: 560 megahertz
RAM Installed: 64 megabyte
Memory Technology: DDR2 SDRAM
Flash Memory Installed: 8 megabyte
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 167 degree Fahrenheit
Operating Humidity: 5 - 95%
Ruggedized Design: Outdoor
Physical Characteristics
Form Factor: External
Status Indicators: LAN, Power, WLAN
Dimensions and Weight
Height: 5.5 inch
Width: 5.5 inch
Depth: 2.1 inch
Weight: 11.29 ounce
Included Items
Included Accessories: Pole mount
Certifications and Listing
Compliant Standards: ETSI 300 019, FCC, IC, IEC 60068-2-11, IEC 60068-2-14, IEC 60068-2-5, IEC 60068-2-6, MIL-STD 810G, RoHS
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
