Product Information
The UniFi Device Bridge Pro is a 5 GHz 802.11ac wireless bridge with a 19 dBi antenna and a listed range of up to 3 miles. It has a Gigabit PoE input port and a Gigabit PoE output port, an IPX6 weatherproof casing, a -40 to 140 °F range and a pole mount. This is a wireless bridge, not an access point.
Key Features
- 5 GHz 802.11ac bridge, 2x2
- 19 dBi antenna
- Up to 3 miles range
- Gigabit PoE in + PoE out
- IPX6, -40 to 140 °F
- Pole mount included
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti UniFi
Model: Device Bridge Pro
Product Type: Wireless bridge
Device Type: Power injector
Packaged Quantity: 1
Color Category: White
Country: United States
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n
Encryption: AES, WPA2
Line Coding Format: 16 QAM, 256 QAM, 64 QAM, BPSK, QPSK
Wireless LAN: 802.11a/n/ac
Network Band: 5 GHz
Network Device: Maximum data rate (5 GHz): 867 Mbps
Antenna Form Factor: Internal
Antenna Gain Level: 19 DBi
Max Range Open Space: 3 miles
Features: 2x2 MIMO technology, Reset button, UV resistant casing, Weatherproof
Connectivity
Interface Provided: 1 x 1000Base-T (PoE input) - RJ-45, 1 x 1000Base-T (PoE output) - RJ-45
Power Over Ethernet (PoE): Passive PoE
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 140 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor: Pole mountable
Status Indicators: Ethernet link/activity, Power, Signal strength
Dimensions and Weight
Height: 7.5 inch
Width: 7.5 inch
Depth: 2.5 inch
Weight: 18.16 ounce
Included Items
Included Accessories: Pole mount, Power cable
Certifications and Listing
Compliant Standards: FCC, IC, IPX6
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
Not sure this fits your network? Send us your controller, switch or current access point model and the DatorPro team will confirm compatibility before you order.
