Product Information
Ubiquiti's UniFi Dream Machine Pro Max is a rack mount gateway and UniFi console with an eight port Gigabit switch, a 10G SFP+ LAN, a 10G SFP+ WAN and a 2.5GbE WAN. It provides 5 Gbps IDS/IPS throughput, two 3.5 inch drive bays, a 128 GB SSD and a 1.3 inch touch screen.
Key Features
- 8 x GbE LAN, 1 x 10G SFP+ LAN
- 1 x 10G SFP+ WAN, 1 x 2.5GbE WAN
- 5 Gbps IDS/IPS
- 2 x 3.5 inch bays, 128 GB SSD
- Quad core 2 GHz, 8 GB RAM, 32 GB flash
- Rack kit included, touch screen
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti UniFi
Model: Dream Machine Pro Max
Product Type: Router
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 2.5 Gigabit Ethernet, Gigabit Ethernet
Network Standard: DHCP, L2TP, OpenVPN, WireGuard
Remote Management: DHCP, IPv6
Routing Protocol: IGMP
Bridge & Router: IDS/IPS throughput: 5 Gbps
Integrated Switch: 8-port switch
Key Features: Firewall, VPN support
Features: 15KV ESD Protector (air-gap discharge), 8KV ESD Protector (contact discharge), Aluminum/steel housing, Bluetooth management, Cloud managed, DHCP relay, DHCP server, IGMP proxy, Interrupt status port (ISP), OpenVPN client, OpenVPN server, Policy-based WAN, Quad-core CPU, Quality of Service (QoS), Reset button, Site-to-Site Replication, VPN routing
Connectivity
Interface Provided: LAN: 1 x 10Gb Ethernet - SFP+, LAN: 8 x 10Base-T/100Base-TX/1000Base-T - RJ-45, WAN: 1 x 10Gb Ethernet - SFP+, WAN: 1 x 2.5G Gigabit Ethernet - RJ-45
Expansion Slots: 2 (total) / 2 (free) x 3.5" HDD bay
WAN Ports Quantity: 2
Power
Device Type: Internal power supply
Memory and Processor
Processor Brand: ARM
Processors Installed: 1
Clock Speed: 2 GHZ
RAM Installed: 8 GB
Memory Technology: DDR4 SDRAM
Flash Memory Installed: 32 GB
Technical Information
Min Operating Temperature: 14 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Desktop
Status Indicators: Disk, Link/activity, RPS (Redundant Power Supply)
Built-in Devices: 1.3" touch screen display, 128 GB SSD
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 11.2 inch
Weight: 10.36 lbs
Included Items
Included Accessories: Power cable
Warranty
Service Activation: No
