Product Information
The Ubiquiti UniFi Gateway Fiber is a desktop cloud managed gateway with a 10GbE RJ-45 WAN, a 10G SFP+ WAN, a 10G SFP+ port and a four port 2.5GbE switch with a 30 W PoE+ budget. It delivers 5 Gbps IDS/IPS throughput and multi-WAN load balancing. No Wi-Fi is built in.
Key Features
- 1 x 10GbE RJ-45 WAN, 1 x 10G SFP+ WAN
- 1 x 10G SFP+, 4 x 2.5GbE with 30 W PoE+
- 5 Gbps IDS/IPS, 55,000 signatures
- WireGuard, OpenVPN, IPsec, L2TP
- Multi-WAN load balancing, layer 7 firewall
- 2.2 GHz ARM CPU, 2 GB flash, no Wi-Fi
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti UniFi
Model: Gateway Fiber
Product Type: Gateway
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 2.5 Gigabit Ethernet
Network Standard: IPSec, L2TP, OpenVPN, WireGuard
Routing Protocol: OSPF
Authentication Method: RADIUS, RADSEC
Capacity: IPS signatures: 55000, MAC table size: 4000
Network Device: IDS/IPS throughput: 5 Gbps
Features: 30W PoE+ power budget, 4KV ESD Protector (contact discharge), 8KV ESD Protector (air-gap discharge), Ad blocking, Advanced QoS, Application-aware layer 7 firewall, Bluetooth management, Content filtering, DNAT support, DPI & traffic identification, Failover backup, Full stateful firewall, Intrusion Detection System (IDS), Intrusion Prevention System (IPS), mDNS, Multi-WAN load balancing, NAT support, Polycarbonate enclosure, Quad-core CPU, RADIUS Server, Reset button, SD-WAN support, SNAT support, VPN client, VPN Server, VPN support, Zone-based firewall advanced filtering
Connectivity
Interface Provided: 1 x 10 Gigabit Ethernet - RJ-45 (WAN), 1 x 10 Gigabit Ethernet - SFP+, 1 x 10 Gigabit Ethernet - SFP+ (WAN), 4 x 2.5Gb Ethernet - RJ-45 - 30 W
Power Over Ethernet (PoE): PoE+
Power
Device Type: External power adapter
Required Voltage: AC 100-240 volt
Memory and Processor
Processor Brand: ARM
Clock Speed: 2.2 GHZ
Flash Memory Installed: 2 GB
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor: Desktop
Status Indicators: Ethernet link/activity, SFP+, System
Built-in Devices: 4-port switch
Dimensions and Weight
Height: 1.2 inch
Width: 8.4 inch
Depth: 5 inch
Weight: 21.34 ounce
Included Items
Included Accessories: Feet set, Power cable
Warranty
Service Activation: No
