Product Information
The Ubiquiti UniFi Protect G2-Pro (UNVR-G2-PRO) is a 2U rack NVR for up to 100 IP cameras with 8 drive bays, a Qualcomm Kryo ARM CPU, 16 GB RAM, 2.5GbE and 10Gb SFP+ networking, HDMI 4K output, Bluetooth management and an SGCC steel enclosure, with universal AC input and RPS DC input. Mounting kit and power cable included. No installed drive is listed, please confirm.
Key Features
- Up to 100 cameras
- 8 drive bays
- 2.5GbE and 10G SFP+
- 16 GB RAM
- HDMI 4K output
- 2U rack mount
Product Information
Quantity Supported: 8
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti UniFi Protect
Model: G2-Pro
Device Type: Standalone NVR
Packaged Quantity: 1
Color Category: Gray
Network and Communication
Network Ports: 2.5GBase-T / 10Gb SFP+
Features #2: Reset button, SGCC steel enclosure, Universal AC input / RPS DC input
Features: 4K resolution support, Bluetooth management, Data Theft Protection, LED status indicators, Manageable
Features: Reset button, SGCC steel enclosure, Universal AC input / RPS DC input
Connectivity
Video Output Ports: HDMI x 1
Power
Input Voltage: 100 - 240 V
Frequency: 50/60 Hz
Power Consumption: 200 watt
Memory and Processor
CPU: Qualcomm Kryo (built on ARM Cortex)
RAM: 16 GB
Technical Information
IP Cameras Supported: 100
Record Events: Analytics
Networked: Yes
Touchscreen: No
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Rack-mountable: Rack-mountable
Height (Rack Units): 2
Dimensions and Weight
Height: 3.4 inch
Width: 17.4 inch
Depth: 12.8 inch
Weight: 18.52 lbs
Included Items
Package Content: Mounting kit, Power Cable
Certifications and Listing
Compliant Standards: FCC, IC, NDAA
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
