Product Information
Ubiquiti's Flex Mini 2.5G (USW-FLEX-2.5G-5) is a compact 5-port Layer 2+ managed switch with all ports at 2.5GbE. It can take power over PoE on one port or from a 5 V external adapter, so it is easy to place on a desk. Switching capacity is 25 Gbps.
Key Features
- 5 x 2.5GbE RJ-45 ports (1 PoE input)
- Layer 2+ managed via UniFi Network
- 25 Gbps switching capacity
- Powered by PoE or 5 V adapter
- Port isolation, mirroring, storm control
- Compact desktop, polycarbonate case
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti UniFi Switch
Model: Flex Mini 2.5G
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: White
Network and Communication
Advanced Switching: Layer 2+
Switching Type: 2.5 Gigabit Ethernet
Manageable: Yes
Routing Protocol: RSTP, STP
Performance: Forwarding rate: 18.6 Mpps, Non-blocking switching throughput: 12.5 Gbps, Switching capacity: 25 Gbps
Features: Egress rate limit, Flow control, Jumbo Frames support, LED status indicators, Loop protection, Multicast/broadcast rate limiting, Polycarbonate enclosure, Port isolation, Port mirroring, Reset button, Storm Control
Features: PoE powered
Connectivity
Ports: 5
Port Quantity: 4
Port Type: 2.5GBase-T
Ports (2nd) Quantity: 1
Ports Type (2nd): 2.5GBase-T (PoE)
Interface Provided: 1 x 2.5GBase-T RJ-45 PoE input, 4 x 2.5GBase-T RJ-45
Power Over Ethernet (PoE): PoE
Power
Device Type: External power adapter
Power Consumption Operational: 5 watt
Provided Voltage: 5 volt
Output Current: 1 ampere
Technical Information
Min Operating Temperature: -4 degree Fahrenheit
Max Operating Temperature: 113 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Desktop
Status Indicators: Link/activity, Speed, Status
Dimensions and Weight
Height: 0.8 inch
Width: 4.6 inch
Depth: 3.5 inch
Weight: 7.27 ounce
Certifications and Listing
Compliant Standards: FCC, IC
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
