Product Information
Ubiquiti's UniFi WAN Switch (USW-WAN) is a compact managed switch for the WAN side of a UniFi network, with three multi-rate SFP+ ports up to 10G and one Gigabit RJ-45 port. It has two internal power supplies for 1+1 redundancy, a steel housing and 20 Gbps of switching capacity.
Key Features
- 3 x 100M/1G/2.5G/5G/10G SFP+ ports
- 1 x Gigabit RJ-45 port
- 20 Gbps switching, 15 Mpps
- 2 internal power supplies, 1+1
- Steel housing, rack mountable
- 2 power cords included
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti UniFi
Model: WAN Switch
Product Type: Switch
Subcategory: Network hubs and switches
Packaged Quantity: 1
Color Category: Gray
Network and Communication
Switching Type: 10 Gigabit Ethernet / 5 Gigabit Ethernet / 2.5 Gigabit Ethernet / Gigabit Ethernet
Manageable: Yes
Performance: Forwarding rate: 15 Mpps, Non-blocking switching throughput: 10 Gbps, Switching capacity: 20 Gbps
Features: 16KV ESD Protector (air-gap discharge), 22KV ESD Protector (contact discharge), Reset button, SGCC steel housing
Connectivity
Port Quantity: 1
Port Type: 10/100/1000
Ports (2nd) Quantity: 3
Ports Type (2nd): 100/1000/2.5G/5G/10G
Interface Provided: 1 x 10/100/1000 Base-T RJ-45, 3 x 100/1000/2.5G/5G/10G SFP+
Power
Device Type: Internal power supply
Required Voltage: AC 100-240 volt
Power Supplies Installed: 2
Power Supplies Supported: 2
Redundant Power Supply Supported: 1+1
Redundant Power Supply: Yes
Technical Information
Min Operating Temperature: 23 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 90% (non-condensing)
Physical Characteristics
Form Factor (Hubs & Switches): Rack-mountable
Height (Rack Units): 1
Status Indicators: Ethernet link/activity, System
Rack Mounting Kit: Included
Dimensions and Weight
Height: 1.7 inch
Width: 17.4 inch
Depth: 4.7 inch
Weight: 4.85 lbs
Included Items
Included Accessories: 2 x power cords, 4 foot pads
Certifications and Listing
Compliant Standards: FCC, IC, NDAA
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
