Product Information
Ubiquiti's Wave AP Gen2 (WAVE-AP-GEN2-US) is a point-to-multipoint base station that serves up to 31 clients over 60 GHz with 5 GHz backup, up to 5.4 Gbps (2.7 Gbps symmetrical) and about 4 miles of range. It has a 90° sector, a 10G SFP+ WAN port and a 2.5G RJ-45, and is rated -40 to 140 °F and IPX6.
Key Features
- 60 GHz PtMP with 5 GHz backup
- Up to 5.4 Gbps, 31 clients
- Range up to 4 miles
- 10G SFP+ WAN, 2.5G RJ-45
- 90° sector, IPX6, -40 to 140 °F
- Passive PoE, pole mount
Product Information
Brand: Ubiquiti
Manufacturer: Ubiquiti
Product Line: Ubiquiti
Model: Wave AP Gen2
Product Type: Wireless access point
Device Type: Power injector
Packaged Quantity: 1
Color Category: White
Network and Communication
Connectivity Technology: Wireless
Data Link Protocols: IEEE 802.11ax (Wi-Fi 6)
Remote Management: SNMP
Encryption: AES, WPA2-PSK
Data Transfer Rate: 5.4 GBps
Line Coding Format: 1024 QAM, 16 QAM, 256 QAM, 64 QAM, BPSK, QPSK
Capacity: Clients per access point: 31
Wireless LAN: 802.11a/b/g/n/ac/ax
Network Band: 5 GHz
Network Device: Channel bandwidth: 20 / 40 / 80 MHz, Symmetrical speed: 2.7 Gbps, Total bandwidth: 5.4 Gbps
Max Range Open Space: 4 miles
Frequency Band: 60 GHZ
Features: 90° sector coverage, Aluminum alloy enclosure, Bridge mode, Dual-linear polarization, NTP client, Ping watchdog, Point-to-Multipoint (PtMP) link mode, UV stabilized polycarbonate enclosure, Wave Technology
Connectivity
Interface Provided: 1 x 10 Gigabit Ethernet - SFP+ (WAN), 1 x 2.5Gb Ethernet - RJ-45
Power Over Ethernet (PoE): Passive PoE
Power
Required Voltage: DC 22 - 27 / 44 - 54 volt
Memory and Processor
Processor Brand: ARM
Processor Number: A53
Processors Installed: 1
Clock Speed: 1.4 GHZ
RAM Installed: 512 megabyte
Memory Technology: DDR3L SDRAM
Technical Information
Min Operating Temperature: -40 degree Fahrenheit
Max Operating Temperature: 140 degree Fahrenheit
Operating Humidity: 5 - 95% (non-condensing)
Physical Characteristics
Form Factor: Pole mountable
Status Indicators: Ethernet link/activity, GPS, Power
Built-in Devices: GPS
Dimensions and Weight
Height: 11.3 inch
Width: 6.2 inch
Depth: 3.9 inch
Weight: 3.31 lbs
Certifications and Listing
Compliant Standards: FCC, IC, IPX6
ENERGY STAR Certified: No
EPEAT Compliant: No
TCO Certified: No
Warranty
Service Activation: No
