Product Information
The Versa CSG750 (CSG750-5G) is a desktop or 1U SD-WAN gateway with up to 2.75 Gbps routing, NGFW, CGNAT, MPLS and a hardware crypto accelerator. It has four gigabit RJ-45, two gigabit RJ-45/SFP combo ports, a management port, an RS-232 console, two USB 2.0 and two SIM slots, with LTE Advanced, dual band Wi-Fi 5 Wave 2 (16 SSIDs, 512 clients), Bluetooth and GPS. A quad core CPU with 8 GB RAM and 64 GB flash adds TPM 2.0 and dual BIOS, and it is passively cooled. The part number says 5G while the spec lists LTE, so please confirm.
Key Features
- SD-WAN gateway
- Up to 2.75 Gbps routing
- LTE, Wi-Fi 5, GPS
- 6 GbE incl. 2 SFP combo
- TPM 2.0, dual BIOS
- Confirm 5G or LTE
Product Information
Brand: Versa
Manufacturer: Versa Networks
Product Line: Versa
Model: CSG750
Product Type: Gateway
Packaged Quantity: 1
Color Category: Gray
Network and Communication
Connectivity Technology: Wired, Wireless
Data Link Protocols: Bluetooth, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, LTE
Routing Protocol: MPLS
Capacity: Number of concurrent clients: 512, SSIDs total: 16
Wireless LAN: 802.11a/b/g/n/ac Wave 2, Bluetooth, LTE
Cellular Data Connectivity Technology: LTE, LTE Advanced
Mobile Broadband Access: Yes
Network Device: Maximum throughput NGFW + AV + SD-WAN: 210 Mbps, Maximum throughput NGFW + AV: 300 Mbps, Maximum throughput NGFW + IPS + SD-WAN: 135 Mbps, Maximum throughput NGFW + IPS, AV + SD-WAN: 110 Mbps, Maximum throughput NGFW + IPS: 160 Mbps, Maximum throughput NGFW + SD-WAN: 700 Mbps, Maximum throughput NGFW + UTM/UTP + SD-WAN: 100 Mbps, Maximum throughput NGFW + UTM/UTP: 125 Mbps, NGFW DIA throughput: 2.3 Gbps, Routing throughput: 2.75 Gbps, SD-WAN site-to-site throughput: 800 Mbps
Features: 2x2 MU-MIMO technology, Access Point operational mode, Beamforming technology, Built-in hardware crypto accelerator, Carrier Grade NAT (CGN/CGNAT), Dual-BIOS, Firewall protection, Maximum Ratio Combining (MRC), Passive cooling, Quad-core CPU, Routing, SD-WAN support, Stateful firewall, Trusted Platform Module 2.0 (TPM 2.0)
Connectivity
Interface Provided: 1 x 1000Base-T (management) - RJ-45, 1 x management (RS-232) - RJ-45, 2 x Ethernet 1000 - RJ-45/SFP (mini-GBIC), 2 x USB 2.0, 4 x Ethernet 1000 - RJ-45
Expansion Slots: 2 (total) / 2 (free) x SIM card
Power
Device Type: External power adapter
Required Voltage: AC 110-240 volt
Frequency: 50/60 hertz
Memory and Processor
RAM Installed: 8 GB
Flash Memory Installed: 64 GB
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 104 degree Fahrenheit
Operating Humidity: 10 - 85%
Physical Characteristics
Form Factor: Desktop / rack mountable
Height (Rack Units): 1
Status Indicators: Status
Built-in Devices: GPS
Dimensions and Weight
Height: 1.8 inch
Width: 13.2 inch
Depth: 8.7 inch
Weight: 5.84 lbs
Certifications and Listing
Compliant Standards: CB, FCC Part 15 A, FIPS 140-2, JPA, JRF, RoHS
Warranty
Service Activation: No
Not sure this device fits your network? Send us your current equipment models and what you need to monitor or manage, and the DatorPro team will confirm compatibility before you order.
