Product Information
The Xilinx Alveo X3522 is a low latency network adapter with four 10/25GbE SFP+/SFP28 ports on a PCI Express 4.0 x8 card. It offers full kernel bypass through Onload and TCPDirect and can be upgraded for user programmability. This is a network adapter, not a CPU.
Key Features
- 4 x 10/25GbE SFP+/SFP28 ports
- PCI Express 4.0 x8, half-height half-length
- 8 GB onboard memory, 400000 LUTs
- Onload and TCPDirect kernel bypass, UEFI support
- Supports RHEL, SUSE Linux Enterprise Server and Ubuntu Server
- 35 W power, full-height and low-profile brackets included
Product Information
Brand: Xilinx
Manufacturer: Xilinx
Product Line: Xilinx Alveo
Model: X3522
Product Type: Network adapter
Packaged Quantity: 1
Color Category: Red
Network and Communication
Connectivity Technology: Wired
Data Link Protocols: 10 Gigabit Ethernet, 25 Gigabit Ethernet
Network Standard: TCP/IP, UDP/IP
Capacity: Look-up tables (LUTs): 400000
Operating System Required: Red Hat Enterprise Linux, SUSE Linux Enterprise Server, Ubuntu Server
Features: Anti-tampering protection, Half-height, half-length (HHHL), MCTP over PCIe VDM, MCTP over SMBus, Network Controller Sideband Interface (NC-SI), TCP Direct, UEFI support, UltraScale+, User-programmable
Connectivity
PCI Specification Revision: PCIe 3.0, PCIe 4.0
Port Quantity: 4
Interface Provided: 4 x 10Gb Ethernet/25Gb Ethernet - SFP+/SFP28
Network & Adapter Ports: 10Gb Ethernet/25Gb Ethernet
Host Interface: PCI Express 4.0 x8
Power
Power Consumption Operational: 35 watt
Memory and Processor
RAM Installed: 8 GB
Technical Information
Min Operating Temperature: 32 degree Fahrenheit
Max Operating Temperature: 131 degree Fahrenheit
Operating Humidity: 10 - 80%
Physical Characteristics
Form Factor: Plug-In Card
Dimensions and Weight
Height: 2.7 inch
Width: 0.7 inch
Depth: 6.6 inch
Included Items
Included Accessories: Full-height bracket, Low-profile bracket
Certifications and Listing
Compliant Standards: Directive 2011/65/EU, FCC, IEEE 1588-2008, Plug and Play, RoHS, UKCA, UL
ENERGY STAR Certified: No
TCO Certified: No
